111
LUBRICATION
SYMBOL DESCRIPTION FREQUENCY
White on Green
High-speed grease
4 points
2 pump strokes every
40 hours of operation
Black on White
Standard grease - 8 points
Grease periodically.
See illustration below for
frequency
Threaded rods - 6 points Oil periodically
CORN CRACKER LUBRICATION
At the beginning of the season, when corn silage is very
”juicy”, it is recoended to have the back sealed chamber
item 1) greased every four hours of operation.
This will prevent the corn juice from contaminating the
grease inside bearings.
1
1
10h40h 40h
LEFT-HAND SIDE
RIGHT-HAND SIDE
High-speed
grease tting
High-speed
grease tting
Figure 153 Closed chamber on the Corn Cracker
Figure 154 Corn Cracker
Manual No. F4117E987E V1.1
