67ECLYPSE APEX
Radius Server/Client Settings
You can use the networkâs RADIUS Server for user authentication management.
RADIUS Server Settings
When
Radius Server
is selected in the
Server Settings
tab, this controller can be used as a RADIUS
server by other controllers on the network. In this scenario, the other controllers must be configured to
use the
Client
RADIUS Server
mode with this controllerâs IP address. This centralizes access manage-
ment on this controller thereby saving time by eliminating the need to add users to each controller indi-
vidually. Set the port numbers and shared key that other controllers will use to connect to this con-
troller. See Supported RADIUS Server Architectures.
The port values of 1812 for authentication and 1813 for accounting are standard RADIUS port num-
bers. However, other port numbers may be used. No matter which port numbers are used, make sure
that the port numbers are unused by other services on this controller and that both the RADIUS server
and the RADIUS clients use the same port number values. See also IP Network Port Numbers and
Protocols.
Figureîˇ55: Radius Server Settings
To setup the RADIUS server settings, complete the parameters as described in the following table:
Item Description
Authentication Port RADIUS server authentication port number.
Accounting Port RADIUS server accounting port number.
Shared Key
Encryption key that devices use to encrypt and decrypt user authentication credentials that are sent
between devices. The shared key should be a long string made up of 16 to 132 random alphanumeric
characters and symbols that would be difficult to guess.
This same key must be copied to any RADIUS client.
Click to copy the shared key to the clipboard.
Click to refresh the information in the list.
Apply Click
Apply
to apply and save the changes
ECLYPSE Web Interface
