Distech Controls ECLYPSE ECY-303 - Variables Reference; Hardware Inputs

13ECY-303 Preloaded Applications
Variables
Hardware Inputs
UI1: UI1 (AI1)
This input is used to connect the Space Temperature, Fan Status, Occupancy Detection, Auxiliary
Contact, Economizer Enable Contact or Window Contact. It is configurable using UI1Config (MSV24)
ID Units Valid Range Default Value
AI1 Ohms (Ω) 0 to 55000 ohms 0 ohms
UI2: UI2 (AI2)
This input is used to connect the Setpoint Offset, Fan Status, Occupancy Detection, Auxiliary Contact,
Economizer Enable Contact or Window Contact. It is configurable using UI2Config (MSV25)
ID Units Valid Range Default Value
AI2 Ohms (Ω) 0 to 55000 ohms 0 ohms
UI3: UI3 (AI3)
This input is used to connect the Return Temperature, Fan Status, Occupancy Detection, Auxiliary
Contact, Economizer Enable Contact or Window Contact. It is configurable using UI3Config (MSV26)
ID Units Valid Range Default Value
AI3 Ohms (Ω) 0 to 55000 ohms 0 ohms
UI4: UI4 (AI4)
This input is used to connect the Discharge Temperature, Fan Status, Occupancy Detection, Auxiliary
Contact, Economizer Enable Contact or Window Contact. It is configurable using UI4Config (MSV27)
ID Units Valid Range Default Value
AI4 Ohms (Ω) 0 to 55000 ohms 0 ohms
UI5: UI5 (AI5)
This input is used to connect the Outdoor Temperature, Fan Status, Occupancy Detection, Auxiliary
Contact, Economizer Enable Contact or Window Contact. It is configurable using UI5Config (MSV28)
ID Units Valid Range Default Value
AI5 Ohms (Ω) 0 to 55000 ohms 0 ohms
UI6: UI6 (AI6)
This input is used to connect the Fan Current, Return Humidity, Discharge Humidity, SpaceHumidity or
Outdoor Humidity. It is configurable using UI6Config (MSV29). The range of the input can also be con-
figured between 0-10V, 2-10V and 4-20mA using UI6Range(MSV20)
ID Units Valid Range Default Value
AI6 Volts (V) 0 to 10 volts 0 volts
