17ECY-303 Preloaded Applications
FanCurrent (AV5)
This variable is used to display the fan current reading. This variable is only used if UI6Config(MSV29)
is configured for FanCurrent reading. The reading of the input can be scaled using MinFanCur-
rent(AV44), MaxFanCurrent(AV45) and UI6Range(MVS20)
ID Units Valid Range Default Value
Analog Value 5 Amperes (A) AV44 to AV45 999 A
SpaceCO2 (AV6)
This variable is used to display the actual space CO2 reading. This variable is only used if UI7Con-
fig(MSV30) is set for SpaceCO2 or either an EC-Smart-Vue or an EC-Smart-Air with –C option is con-
nected to the system. The reading of input UI7 can be scaled using MinRangeCO2(AV57),
MaxRangeCO2(AV56) and UI7Range(MVS21)
ID Units Valid Range Default Value
Analog Value 6 ppm 250 ppm to AV56 999 ppm
ReturnCO2 (AV7)
This variable is used to display the actual return CO2 reading. This variable is only used if UI8Con-
fig(MSV31) is set for ReturnCO2. The reading of input UI8 can be scaled using MinRangeCO2(AV57),
MaxRangeCO2(AV56) and UI8Range(MVS22)
ID Units Valid Range Default Value
Analog Value 7 ppm 250 ppm to AV56 999 ppm
OutdoorTemp (AV8)
This variable is used to display the actual outdoor temperature from UI5 Input. This variable can be
used to override the outdoor temperature. It is only used if UI5Config(MSV27) is configured for Out-
doorTemp.
ID Units Valid Range Default Value
Analog Value 8 Degrees-Celsius (°C) -50 to 65°C 999°C
ReturnHumidity (AV9)
This variable is used to display the actual return humidity from either UI6, UI7 or UI8 Input. This vari-
able can be used to override the return humidity. It is only used if either UI6Config(MSV28), UI7Con-
fig(MSV29) or UI7Config(MSV30) is configured for ReturnHumidity. The reading of the inputs can be
scaled using UI6Range(MVS20), UI7Range(MVS21) or UI8Range(MVS22).
ID Units Valid Range Default Value
Analog Value 9 % RH 5 to 100%RH 999%RH
DischargeHumidity (AV10)
This variable is used to display the actual discharge humidity from either UI6, UI7 or UI8 Input. This
variable can be used to override the discharge humidity. It is only used if either UI6Config(MSV28),
UI7Config(MSV29) or UI7Config(MSV30) is configured for DischargeHumidity. The reading of the in-
puts can be scaled using UI6Range(MVS20), UI7Range(MVS21) or UI8Range(MVS22).
ID Units Valid Range Default Value
Analog Value 10 % RH 5 to 100%RH 999%RH
