39ECY-303 Preloaded Applications
ID Enumeration Default Value
Multi State Value 34
1 = Unconfig: The unit is not equipped with a proportional heating stage
2 = Analog 0-10V: The unit is equipped with a 0-10V heating stage
3 = Analog 2-10V: The unit is equipped with a 2-10V heating stage
4 = PWM: The unit is equipped with a PWM heating stage
Unconfig
DampersConfig (MSV35)
This variable is used to configure the fan control mode based on the OccupancyStatus.
ID Enumeration Default Value
Multi State Value 35
1 = Unconfig : The unit is not equipped with fresh air dampers
2 = Analog 0-10V : The unit is equipped with 0-10V fresh air dampers
3 = Analog 2-10V : The unit is equipped with 2-10V fresh air dampers
4 = Analog 0-10V PE: The unit is equipped with 0-10V fresh air
dampers and a power exhaust
5 = Analog 2-10V PE: The unit is equipped with 2-10V fresh air
dampers and a power exhaust
6 = Econ Enable: The unit is equipped with a locally controlled
economizer. The damper output is used to enable/disable the local
economizer control.
7 = Econ & Min Pos: The unit is equipped with a locally controlled
economizer. 2 outputs are used in this mode, one to enable the
minimum position and one to enable the economizer.
8 = MinPos Enable: The unit is equipped with an economizer. The
damper output is used to enable/disable minimum damper position. The
economizer is locally controlled based on settings from the local
economizer.
Unconfig
HumidifierConfig (MSV36)
This variable is used to configure the humidifier type.
ID Enumeration Default Value
Multi State Value 36
1 = Unconfig : The unit is not equipped with a humidifier
2 = Analog 0-10V : The unit is equipped with a 0-10V humidifier
3 = Analog 2-10V : The unit is equipped with a 2-10V humidifier
4 = PWM: The unit is equipped with a PWM humidifier
5 = Digital: The unit is equipped with a digital (On/Off) humidifier
Unconfig
Output2ConfigSt (MSV37)
This variable is used to display the output configuration of output 2. Changing the value of this object
from the BACnet network will not change the output assignment of the unit. This Value is for informa-
tion only.
Variables
