28 ECY-303 Preloaded Applications
ID Units Valid Range Default Value
Analog Value 87 Delta-Degrees-Celsius (∆°C) 0 to 5∆°K 3∆°K
SpaceTempOffset (AV88)
This variable is used to calibrate the temperature reading of the controller. This value will be added to
the temperature reading (Hardware input, EC-Smart-Vue, EC-Smart-Air) to calculate the resulting
space temperature (AV1).
ID Units Valid Range Default Value
Analog Value 88 Delta-Degrees-Celsius (∆°C) -5 to 5 ∆°C 0∆°C
ReturnTempOffset (AV89)
This variable is used to calibrate the temperature reading of the controller. This value will be added to
the temperature reading of UI3 to calculate the resulting return temperature (AV3).
ID Units Valid Range Default Value
Analog Value 89 Delta-Degrees-Celsius (∆°C) -5 to 5 ∆°C 0∆°C
DischTempOffset (AV90)
This variable is used to calibrate the temperature reading of the controller. This value will be added to
the temperature reading of UI4 to calculate the resulting discharge temperature (AV4).
ID Units Valid Range Default Value
Analog Value 90 Delta-Degrees-Celsius (∆°C) -5 to 5 ∆°C 0∆°C
AppVersion (AV100)
This variable is used to display the current version number of the application.
ID Units Valid Range Default Value
Analog Value 100 N/A N/A 0.0
Binary Values
Cool1 (BV1)
This variable is used to display the actual cooling stage 1 output value. When the system is configured
in heat pump mode, this output represents the compressor stage 1 output.
ID Units Valid Range Default Value
Binary Value 1 On/Off On to Off Off
Cool2 (BV2)
This variable is used to display the actual cooling stage 2 output value. When the system is configured
in heat pump mode, this output represents the compressor stage 2 output.
ID Units Valid Range Default Value
Binary Value 2 On/Off On to Off Off
Cool3 (BV3)
This variable is used to display the actual cooling stage 3 output value. When the system is configured
in heat pump mode, this output represents the compressor stage 3 output.
