26 ECY-303 Preloaded Applications
CoolingStgsLoad (AV68)
This variable is used to display the percentage of cooling stages active. This variable is used for the
HMI.
ID Units Valid Range Default Value
Analog Value 68 Percent (%) 0 to 100% -1%
HeatingStgsLoad (AV69)
This variable is used to display the percentage of heating stages active. This variable is used for the
HMI.
ID Units Valid Range Default Value
Analog Value 69 Percent (%) 0 to 100% -1%
ComSensorMinCoolSP (AV75)
This variable is used to calculate the minimum value that can be configured for the occupied cooling
setpoint by the end user from the EC-Smart-Vue. The minimum value is equal to the maximum be-
tween ComSensorMinCoolSp and StandbyHeatSp + 0.7°ΔF (0.4°ΔK)
ID Units Valid Range Default Value
Analog Value 75 Degrees-Celsius (°C) N/A 19,5 °C
ComSensorMaxCoolSP (AV76)
This variable is used to calculate the maximum value that can be configured for the occupied cooling
setpoint by the end user from the EC-Smart-Vue. The maximum value is equal to the minimum be-
tween ComSensorMaxCoolSp and StandbyCoolSp - 0.5°ΔF (0.2°ΔK)
ID Units Valid Range Default Value
Analog Value 76 Degrees-Celsius (°C) N/A 26,7 °C
ComSensorMinHeatSP (AV77)
This variable is used to calculate the minimum value that can be configured for the occupied Heating
setpoint by the end user from the EC-Smart-Vue. The minimum value is equal to the maximum be-
tween ComSensorMinHeatSp and StandbyHeatSp + 0.5°ΔF (0.2°ΔK)
ID Units Valid Range Default Value
Analog Value 77 Degrees-Celsius (°C) N/A 15,5 °C
ComSensorMaxHeatSP (AV78)
This variable is used to calculate the maximum value that can be configured for the occupied Heating
setpoint by the end user from the EC-Smart-Vue. The maximum value is equal to the minimum be-
tween ComSensorMaxHeatSp and StandbyCoolSp - 0.7°ΔF (0.4°ΔK).
ID Units Valid Range Default Value
Analog Value 78 Degrees-Celsius (°C) N/A 24 °C
DischTempCoolSP (AV79)
This variable is used to calculate if another cooling stage is required to cool the space. When the
space temperature is requiring cooling, cooling stages will be turned on only if the discharge tempera-
ture is above DischTempCoolSP(AV79).
ID Units Valid Range Default Value
Analog Value 79 Degrees-Celsius (°C) 4,5 to 18°C 7°C
Variables
