43ECY-303 Preloaded Applications
ID Enumeration Default Value
Multi State Value 43
1 = Unconfig : The unit is not equipped with a humidifier
2 = Cool1 : The output is used to control cooling/compressor stage 1
3 = Cool2 : The output is used to control cooling/compressor stage 2
4 = Cool3 : The output is used to control cooling/compressor stage 3
5 = Cool4 : The output is used to control cooling/compressor stage 4
6 = Heat1 : The output is used to control heating stage 1
7 = Heat2 : The output is used to control heating stage 2
8 = Heat3 : The output is used to control heating stage 3
9 = Min Position : The output is used to control the minimum position of
the dampers
10 = Reversing Valve : The output is used to control the reversing valve
of a heat pump unit
11 = Prop Heating : The output is used to control a proportional heating
stage
12 = Dampers : The output is used to control the dampers
13 = Humidier : The output is used to control the humidifier
14 = Power Exhaust : The output is used to control a damper power
exhaust
Unconfig
PropHeatGx (MSV45)
This variable is used to display the stage number of the proportional heating for the Envsyion graph-
ics.
ID Enumeration Default Value
Multi State Value 45
1 = Stage1 : The proportional heating stage is the stage 1 of heating
2 = Stage2 : The proportional heating stage is the stage 2 of heating
3 = Stage3 : The proportional heating stage is the stage 3 of heating
4 = Unconfig : The proportional heating stage is not configured
Unconfig
