Distech Controls ECLYPSE ECY-303 - Comsensorsptype (MSV16); Comsensorlock (MSV19); Ui6 Range (MSV20); Ui7 Range (MSV21)

35ECY-303 Preloaded Applications
ID Enumeration Default Value
Multi State Value 15
1 = Occupied: The hvac controller should operate in the occupied mode
2 = Unoccupied: The hvac controller should operate in the unoccupied
mode
3 = Bypass: The hvac controller should operate in the occupied mode
4 = Standby: The Space Comfort Controller should operate in the
standby mode
N/A
ComSensorSpType (MSV16)
This variable is used to configure how the setpoint should be displayed and changed from the EC-
Smart-Vue.
ID Enumeration Default Value
Multi State Value 16
1 = CoolHeatSP: Occupied Cooling and Heating setpoints changed
from EC-Smart-Vue
2 = SpOffset: Setpoint Offset available to be changed from EC-Smart-
Vue
3 = SingleSp: Used to change midSetpoint or single setpoint based on
deadband (heat and cool)
CoolHeatSP
ComSensorLock (MSV19)
This variable is used to configure the access level of the end user from the EC-Smart-Vue.
ID Enumeration Default Value
Multi State Value 19
1 = FullAccess: User can access all of the EC-Smart-Vue menus and
configuration
2 = Sp&FanMode: User can change setpoints and fan mode only
3 = SpOnly: User can only change setpoints
4 = NoAccess: User can only view information
FullAccess
UI6Range (MSV20)
This variable is used to configure the range of the input UI6.
ID Enumeration Default Value
Multi State Value 20
1 = 0-10V: The range is from 0 to 10 V
2 = 2-10V: The range is from 2 to 10 V
3 = 4-20mA: The range is from 4 to 20 mA
4 = 0-5V : The range is from 0 to 5 V
0-10V
UI7Range (MSV21)
This variable is used to configure the range of the input UI7.
ID Enumeration Default Value
Multi State Value 21
1 = 0-10V: The range is from 0 to 10 V
2 = 2-10V: The range is from 2 to 10 V
3 = 4-20mA: The range is from 4 to 20 mA
4 = 0-5V : The range is from 0 to 5 V
0-10V
UI8Range (MSV22)
This variable is used to configure the range of the input UI8.
Variables
