45ECY-303 Preloaded Applications
ID Units Valid Range Default Value
PID4 Percent (%) 0 to 100% N/A
PID_PropHeat (loop5)
This variable is used to display the actual proportional heating loop value.
The following parameters of this loop can be modified to adjust the response of the controller.
ProportionalConstant, default value = 10°C
IntegralConstant, default value = 300 seconds
DerivativeConstant, default value = 0 seconds
Bias, default value = 50%
ID Units Valid Range Default Value
PID5 Percent (%) 0 to 100% N/A
PID_Hum (loop6)
This variable is used to display the actual humidifier loop value.
The following parameters of this loop can be modified to adjust the response of the controller.
ProportionalConstant, default value = 5 %RH
IntegralConstant, default value = 0 seconds
DerivativeConstant, default value = 0 seconds
Bias, default value = 50%
ID Units Valid Range Default Value
PID6 Percent (%) 0 to 100% N/A
PID_DischHum (loop7)
This variable is used to display the actual discharge humidity limit loop value.
The following parameters of this loop can be modified to adjust the response of the controller.
ProportionalConstant, default value = 20 %RH
IntegralConstant, default value = 0 seconds
DerivativeConstant, default value = 0 seconds
Bias, default value = 50%
ID Units Valid Range Default Value
PID7 Percent (%) 0 to 100% N/A
PID_Dehum (loop8)
This variable is used to display the actual dehumidification loop value.
The following parameters of this loop can be modified to adjust the response of the controller.
ProportionalConstant, default value = 5 %RH
IntegralConstant, default value = 0 seconds
DerivativeConstant, default value = 0 seconds
Bias, default value = 50%
ID Units Valid Range Default Value
PID8 Percent (%) 0 to 100% N/A
