16 ECY-303 Preloaded Applications
been made, the variable Output7ConfigSt(MSV42) will display what needs to be wired to this output.
See section IO assignment for more details.
ID Units Valid Range Default Value
AO7 Percent (%) 0 to 100% 0%
AO8: AO8 (AO8)
This output is used to control the various possible equipements of the unit (Cooling stage, heating
stage, economizer, etc) based on the configuration of CoolHeatConfig (MSV32), RevValveConfig(
MSV33), DampersConfig(MSV35), HumidifierConfig(MSV36). Once all the configurations have
been made, the variable Output8ConfigSt(MSV43) will display what needs to be wired to this output.
See section IO assignment for more details.
ID Units Valid Range Default Value
AO8 Percent (%) 0 to 100% 0%
Analog Values
SpaceTemp (AV1)
This variable is used to display the actual space temperature used by the controller. This variable can
be used for testing purposes by overriding the value using the BACnet priority array. The value of this
variable depends on the readings of UI1 (If UI1Config = SpaceTemp), the EC-Smart-Vue, the EC-
Smart-Comfort or the EC-Smart-Air. The priority of this input is the following : UI1, EC-Smart-Vue and
EC-Smart-Comfort/Air.
ID Units Valid Range Default Value
Analog Value 1 Degrees-Celsius (°C) -10 to 50°C 999°C
SetPtOffset (AV2)
This variable is used to display the actual setpoint offset value.
ID Units Valid Range Default Value
Analog Value 2 Delta-Degrees-Celsius (∆°C) - AV87 to AV87 999∆°C
ReturnTemp (AV3)
This variable is used to display the actual return temperature from UI3 Input. This variable can be
used to override the return temperature. It is only used if UI3Config(MSV25) is configured for Return-
Temp.
ID Units Valid Range Default Value
Analog Value 3 Degrees-Celsius (°C) -15 to 65°C 999°C
DischargeTemp (AV4)
This variable is used to display the actual discharge temperature from UI4 Input. This variable can be
used to override the discharge temperature. It is only used if UI4Config(MSV26) is configured for Dis-
chargeTemp.
ID Units Valid Range Default Value
Analog Value 4 Degrees-Celsius (°C) -15 to 65°C 999°C
