40 ECY-303 Preloaded Applications

ID Enumeration Default Value

Multi State Value 37

1 = Unconfig : The unit is not equipped with a humidifier

2 = Cool1 : The output is used to control cooling/compressor stage 1

3 = Cool2 : The output is used to control cooling/compressor stage 2

4 = Cool3 : The output is used to control cooling/compressor stage 3

5 = Cool4 : The output is used to control cooling/compressor stage 4

6 = Heat1 : The output is used to control heating stage 1

7 = Heat2 : The output is used to control heating stage 2

8 = Heat3 : The output is used to control heating stage 3

9 = Min Position : The output is used to control the minimum position of

the dampers

10 = Reversing Valve : The output is used to control the reversing valve

of a heat pump unit

11 = Prop Heating : The output is used to control a proportional heating

stage

12 = Dampers : The output is used to control the dampers

13 = Humidier : The output is used to control the humidifier

14 = Power Exhaust : The output is used to control a damper power

exhaust

Unconfig

Output3ConfigSt (MSV38)

This variable is used to display the output configuration of output 3. Changing the value of this object

from the BACnet network will not change the output assignment of the unit. This value is for informa-

tion only.
