30 ECY-303 Preloaded Applications
ID Units Valid Range Default Value
Binary Value 11 Enable/Disable Enable to Disable Enable
FanStatus (BV12)
This variable is used to display the actual fan status. When no inputs are configured for either FanSta-
tus or FanCurrent, this variable is equal to the Fan Command (BO1). When UI6 is configured for Fan-
Current, this variable is set based on FanOnSetpoint(AV59) and FanOffSetpoint(AV60).
ID Units Valid Range Default Value
Binary Value 12 On/Off On to Off Off
EconEquip (BV13)
This variable is used to indicate if the unit is equipped with an economiser. When set to Yes, the cool-
ing stage 1 will always be enable to provide for economiser control.
ID Units Valid Range Default Value
Binary Value 13 Yes/No Yes to No No
EnableDehumid (BV14)
This variable is used to configure if the unit can use cooling stages for dehumidification.
ID Units Valid Range Default Value
Binary Value 14 Enable/Disable Enable to Disable Disable
EnableMinPosStandby (BV15)
This variable is used to configure if the dampers should be set to min position while in standby mode.
When this variable is disable, the dampers are set to min position only in occupied mode.
ID Units Valid Range Default Value
Binary Value 15 Enable/Disable Enable to Disable Disable
GasHeating (BV16)
This variable is used to configure the type of heating (electric or gas) for the shedding sequence.
When this variable is set to Gas, the shedding is disabled.
ID Units Valid Range Default Value
Binary Value 16 Gas/Electric Gas to Electric Electric
LowLimitAlarm (BV17)
This variable is used to indicate if the system is in low limit alarm mode.
ID Units Valid Range Default Value
Binary Value 17 Alarm/Normal Alarm to Normal Normal
LowLimitReset (BV18)
This variable is used to reset the LowLimitAlarm variable and restart the unit.
ID Units Valid Range Default Value
Binary Value 18 Reset/Normal Reset to Normal Normal
Variables
