15ECY-303 Preloaded Applications
DO2: DO2 (DO2)
This output is used to control the cooling stage 1 of the unit.
ID Units Valid Range Default Value
DO2 On/Off On to Off Off
DO3: DO3 (DO3)
This output is used to control the various possible equipements of the unit (Cooling stage, heating
stage, economizer, etc) based on the configuration of CoolHeatConfig (MSV32), RevValveConfig(
MSV33), DampersConfig(MSV35), HumidifierConfig(MSV36). Once all the configurations have
been made, the variable Output3ConfigSt(MSV38) will display what needs to be wired to this output.
See section IO assignment for more details.
ID Units Valid Range Default Value
DO3 On/Off On to Off Off
DO4: DO4 (DO4)
This output is used to control the various possible equipements of the unit (Cooling stage, heating
stage, economizer, etc) based on the configuration of CoolHeatConfig (MSV32), RevValveConfig(
MSV33), DampersConfig(MSV35), HumidifierConfig(MSV36). Once all the configurations have
been made, the variable Output4ConfigSt(MSV39) will display what needs to be wired to this output.
See section IO assignment for more details.
ID Units Valid Range Default Value
DO4 On/Off On to Off Off
DO5: DO5 (DO5)
This output is used to control the various possible equipements of the unit (Cooling stage, heating
stage, economizer, etc) based on the configuration of CoolHeatConfig (MSV32), RevValveConfig(
MSV33), DampersConfig(MSV35), HumidifierConfig(MSV36). Once all the configurations have
been made, the variable Output5ConfigSt(MSV40) will display what needs to be wired to this output.
See section IO assignment for more details.
ID Units Valid Range Default Value
DO5 On/Off On to Off Off
AO6: AO6 (AO6)
This output is used to control the various possible equipements of the unit (Cooling stage, heating
stage, economizer, etc) based on the configuration of CoolHeatConfig (MSV32), RevValveConfig(
MSV33), DampersConfig(MSV35), HumidifierConfig(MSV36). Once all the configurations have
been made, the variable Output6ConfigSt(MSV41) will display what needs to be wired to this output.
See section IO assignment for more details.
ID Units Valid Range Default Value
AO6 Percent (%) 0 to 100% 0%
AO7: AO7 (AO7)
This output is used to control the various possible equipements of the unit (Cooling stage, heating
stage, economizer, etc) based on the configuration of CoolHeatConfig (MSV32), RevValveConfig(
MSV33), DampersConfig(MSV35), HumidifierConfig(MSV36). Once all the configurations have
