Distech Controls ECLYPSE ECY-303 - Ui5 Config (MSV28); Ui6 Config (MSV29); Ui7 Config (MSV30)

37ECY-303 Preloaded Applications
ID Enumeration Default Value
Multi State Value 27
1 = Unconfig : Hardware Input is not used
2 = DischTemp : The input is used to connect a Discharge temperature
sensor
3 = FanStatus : The input is used to connect a digital fan status input
4 = OccDetect : The input is used to connect a motion detection sensor
5 = AuxiliaryContact: The input is used to connect an auxiliary contact
6 = EconEnable : The input is used to connect an economizer enable
input.
7 = Window : The input is used to connect a window contact
DischTemp
UI5Config (MSV28)
This variable is used to configure the source of Hardware Input 5.
ID Enumeration Default Value
Multi State Value 28
1 = Unconfig : Hardware Input is not used
2 = OutdoorTemp : The input is used to connect a outdoor temperature
sensor
3 = FanStatus : The input is used to connect a digital fan status input
4 = OccDetect : The input is used to connect a motion detection sensor
5 = AuxiliaryContact: The input is used to connect an auxiliary contact
6 = EconEnable : The input is used to connect an economizer enable
input.
7 = Window : The input is used to connect a window contact
OutdoorTemp
UI6Config (MSV29)
This variable is used to configure the source of Hardware Input 6.
ID Enumeration Default Value
Multi State Value 29
1 = Unconfig : Hardware Input is not used
2 = FanStatus : The input is used to connect an analog fan current input
3 = ReturnHumid : The input is used to connect a return humidity
sensor
4 = DischHumid : The input is used to connect a discharge humidity
sensor
5 = SpaceHumid : The input is used to connect a space humidity sensor
6 = OutdoorHumid : The input is used to connect an outdoor humidity
sensor
Unconfig
UI7Config (MSV30)
This variable is used to configure the source of Hardware Input 7.
ID Enumeration Default Value
Multi State Value 30
1 = Unconfig : Hardware Input is not used
2 = SpaceCO2 : The input is used to connect a space CO2 sensor
3 = ReturnHumid : The input is used to connect a return humidity
sensor
4 = DischHumid : The input is used to connect a discharge humidity
sensor
5 = SpaceHumid : The input is used to connect a space humidity sensor
6 = OutdoorHumid : The input is used to connect an outdoor humidity
sensor
SpaceCO2
Variables
