DOGA DPC TOUCH V2 - Page 26

User manual DPC Touch V2 DOC.60352-11/20
26
To register location of a corresponding corner, position the arm and press Pick
button.
Encoders turn light blue and output is activated when rest position is reached.
Information
the real shape of pick-up area is not rectangular and depends on the
geometry of the arm.
