Information
Select DC tool interface in DPC Touch operating settings.
In order to use 24V supply from Stanley controller, short connect pins
A and B. In this case DPC Touch will be powered by Stanley controller.
Don’t connect DPC Touch to external power in this case.
8.2.6. Connection of KOLVER EDU tools
DPC Touch V2
KOLVER série EDU
I/O Adaptor
(DB44 male to DB9 female
& DB25 female)
CN1 port
(10 contacts)
