4.4.2 Fastening step creation
Information
it is useful to define encoder’s reference/zero point before creating a
fastening step (please refer to paragraph 3.4.3).
While on the Job creation screen, tap the FASTENING step button. The
Fastening step creation screen will appear:
Position - CURRENT
Displays the number of positions being programmed
Position - SAVED
Displays the total number of saved positions in the
fastening step being programmed
Position Manager informations:
Position Manager CH
1 to 4 - Current
Displays current values from analog encoders.
Only active channels are shown.
Position Manager CH
1 to 4 - Saved
Displays saved values from analog encoders.
Current values are saved when then Apply button is
pressed or when the Fastening OK signal is
received.
Tolerance, pts -
(orange)
Approaching area
Displays the encoder tolerance value (in number of
encoder points on either side of the screwing
position) applicable to the orange zone (where the
tool is allowed to exit the green zone during
screwing).
Tolerance, pts - OK
(Green)
OK zone
Displays the encoder tolerance value (in number of
encoder points on either side of the screw position)
applicable to the green zone (where the tool is
allowed to operate).
