User manual DPC Touch V2 DOC.60352-11/20
8
1.4 Standard Equipment Presentation
1.4.1 DPC Touch V2 Controller
1
SD Card
6
1 : GX, GY, DO, GA
2
USB mini-B port *
7
2 : GX, GY, DO, GA
3
USB-B port *
8
I/O port (DB44
)
4
Power Supply
9
Encoders port (DB9)
5
Ethernet Port
10
Barcode reader (RS-232)
* Not activated.
