3.5 Controller Parameters - Inputs
Activate necessary inputs by selecting corresponding check boxes.
Select required input function from the list.
Non-assigned inputs can be used for Logical In steps.
Impulse signals duration must be between 100 and 500 ms.
Information
Each input function can be assigned only once.
Input Name
Function description
Signal type
Job select 1-8
Inputs to select jobs on DPC Touch in binary or
in direct logic (see the table below). Logic is
selected in operating settings.
Continuous
Skip
Signal is used to skip the current step or
position.
Impulse
Back
Signal is used to get back to previous position.
It’s not possible to get back to previous step.
Impulse
Reset
DPC Touch alarm reset. If maximum number of
retightenings is reached it’s not possible to
reset the alarm. Step or Job has to be reset.
Impulse
Reset Step
Signal is used to reset current fastening step.
Impulse
Reset Job
Signal is used to reset current job.
Impulse
Next Job
Signal is used to select next job in the job
manager list.
Impulse
Previous Job
Signal is used to select previous job in the job
manager list.
Impulse
