3.7 Controller Parameters - Network
3.7.1 Network - RS-232 - Serial Communication
Activate (ON) or deactivate (OFF) the serial communication and/or external
trigger start for the use of the RS232 serial port of the DPC Touch V2
controller.
When serial communication is enabled, you must then set the communication
mode in COM 1 or COM 2 settings.
Warning
Refer to the RS-232 connector wiring diagram in the appendix of
the document. In case of COM1 and COM2 use, an adapter is
required to separate the ports, contact the DOGA service.
2 possible options in COM settings: barcode and RS-232.
Once the mode is selected, enter the transmission rate.
You have 5 possibilities: 9600, 19200, 38400, 57600 and 115200. This choice
will depend on the hardware connected to the DPC Touch V2 controller.
If you select the barcode, please go the screen n°3/3 so in order to start the
recognition of the barcode(s) that will be used for job calls (see paragraph
3.7.3.).
Warning
Do not use a RS-232 standard cable, you must adapt the wiring.
Please refer to the RS-232 connector wiring scheme in Appendix.
