User manual DPC Touch V2 DOC.60352-11/20
4.4.9 Delay step creation
While on Job modification screen, tap the DELAY button. The Delay step
creation screen will appear.
There are three types of delay steps:
The controller will stay on hold for the defined time.
Delay step can be used to manage timing between Logical
In and Logical Out steps or between messages.
Enter the barcode (up to 32 alphanumerical characters) and
filter it according to the defined criteria.
Using the START and END criteria filters the portion of the
barcode to be read. Here are the filtering rules:
Barcode is not read, any
barcode will valid the step.
If START and END:
Between 1 and 32
Barcode is read only
between the defined values.
User will see a confirmation message Box «Are you
Sure?».
Press the SAVE button to save the step, or the CANCEL button to quit
programming without saving changes.
