8.3 Modbus TCP/IP addresses
Adr.
Operation
Description
Function Code
1
Tool selection
2: GX/GY/DO/GA
3: DC Tools
0x03/0x06
2
Screws counting up
0: Not use 1: Use
0x03/0x06
3
Screw counting for step
0: Not use 1: Use
0x03/0x06
4
Torque selection by binary outputs
0: Not use 1: Use
0x03/0x06
5
Job selection by binary inputs
0: Not use 1: Use
0x03/0x06
6
Default job number
value = Job no
0x03/0x06
7
Skip button access without password
0: Not use 1: Use
0x03/0x06
8
Back button access without password
0: Not use 1: Use
0x03/0x06
9
Reset button access without password
0: Not use 1: Use
0x03/0x06
10
Job selection access without password
0: Not use 1: Use
0x03/0x06
11
Display job reset button
0: Not use 1: Use
0x03/0x06
12
Min fastening time limit %
value <= 25
0x03/0x06
13
Max fastening time limit %
value <= 25
0x03/0x06
14
Start trigger release time limit(ms)
value <= 9999
0x03/0x06
15
Temporary position loss time(ms)
value <= 3000
0x03/0x06
16
Judge Time(ms)
value <= 500
0x03/0x06
17
Number of retightening on a position
value <= 9
0x03/0x06
18
Skip NG tightening
0: Not use 1: Use
0x03/0x06
19
Fastening NG signal if position skipped
0: Not use 1: Use
0x03/0x06
20
Auto reset delay(ms)
value <= 9999
0x03/0x06
21
Automatically restart the job when
finished
0: Not use 1: Use
0x03/0x06
22
Store logs during operation
0: Not use 1: Use
0x03/0x06
23
Skip by step
0: Not use 1: Use
0x03/0x06
