User manual DPC Touch V2 DOC.60352-11/20
90
Adr.
Operation
Description
Function code
100
Use Channel1
0: Not use 1: Use
0x03/0x06
101
Use Channel2
0: Not use 1: Use
0x03/0x06
102
Use Channel3
0: Not use 1: Use
0x03/0x06
103
Use Channel4
0: Not use 1: Use
0x03/0x06
104
Ch1 Position Area tolerance
value <= 4000
0x03/0x06
105
Ch2 Position Area tolerance
value <= 4000
0x03/0x06
106
Ch3 Position Area tolerance
value <= 4000
0x03/0x06
107
Ch4 Position Area tolerance
value <= 4000
0x03/0x06
108
Ch1 Position Ok tolerance
value <= 4000
0x03/0x06
109
Ch2 Position Ok tolerance
value <= 4000
0x03/0x06
110
Ch3 Position Ok tolerance
value <= 4000
0x03/0x06
111
Ch4 Position Ok tolerance
value <= 4000
0x03/0x06
112
Use Pickup Position 1 Corner1
0: Not use 1: Use
0x03/0x06
113
Use Pickup Position 1 Corner2
0: Not use 1: Use
0x03/0x06
114
Use Pickup Position 2 Corner1
0: Not use 1: Use
0x03/0x06
115
Use Pickup Position 2 Corner2
0: Not use 1: Use
0x03/0x06
116
Pickup Position 1 Corner 1 Channel 1
-4095<= v <=4095
0x03/0x06
117
Pickup Position 1 Corner 2 Channel 1
-4095<= v <=4095
0x03/0x06
118
Pickup Position 2 Corner 1 Channel 1
-4095<= v <=4095
0x03/0x06
119
Pickup Position 2 Corner 2 Channel 1
-4095<= v <=4095
0x03/0x06
120
Pickup Position 1 Corner 1 Channel 2
-4095<= v <=4095
0x03/0x06
121
Pickup Position 1 Corner 2 Channel 2
-4095<= v <=4095
0x03/0x06
122
Pickup Position 2 Corner 1 Channel 2
-4095<= v <=4095
0x03/0x06
123
Pickup Position 2 Corner 2 Channel 2
-4095<= v <=4095
0x03/0x06
124
Ch1 Zero position
value <= 4095
0x03/0x06
125
Ch2 Zero position
value <= 4095
0x03/0x06
126
Ch3 Zero position
value <= 4095
0x03/0x06
127
Ch4 Zero position
value <= 4095
0x03/0x06
