User manual DPC Touch V2 DOC.60352-11/20
91
Adr.
Network
Description
Function Code
300
Serial communication enable
0: Not use 1: Use
0x03/0x06
301
External start trigger
0: Not use 1: Use
0x03/0x06
302
Comport 1 mode
0: Not use 1: Barcode 2:
RS-232
0x03/0x06
303
Comport 2 mode
0: Not use 1: Barcode 2:
RS-232
0x03/0x06
304
Comport 1 baudrate
0: 9600 1: 19200 2: 38400
3: 57600 4:115200
0x03/0x06
305
Comport 2 baudrate
0: 9600 1: 19200 2: 38400
3: 57600 4:115200
0x03/0x06
Adr.
Input
Description
Function Code
200
Input value
0000 1111 1111 1111 1111 (16bit
value) LSB is input no.1 MSB is input
no.12
0x03/0x06
201
Input 1 type
0x03/0x06
202
Input 2 type
0x03/0x06
203
Input 3 type
0x03/0x06
204
Input 4 type
0x03/0x06
205
Input 5 type
0x03/0x06
206
Input 6 type
0x03/0x06
207
Input 7 type
0x03/0x06
208
Input 8 type
0x03/0x06
209
Input 9 type
0x03/0x06
210
Input 10 type
0x03/0x06
211
Input 11 type
0x03/0x06
212
Input 12 type
0x03/0x06
