DOGA DPC TOUCH V2 - Page 88

User manual DPC Touch V2 DOC.60352-11/20
88
DPC Touch
DB44 (male)
DB25 (female)
DB9 (female)
OUT_COM
29
23, 24
9
30 *
+24V
31 *
32
33
0V
35 **
36
37
Warning
By default, the controller provides 24V output on the pins 31-32-33 &
0V pins 35-36-37. Its power supply can only be used to power I/O
signals (max 100mA per output, max 500mA for all outputs).
The controller can also be powered by external power supply through I/O port.
Bridges between pins (15-35)** & (30-31)* are made inside DB44 male
connector.
Information
Pins n°13,28, 34, 38,39 40,41, 42, 43, 44 are not used.
