User manual DPC Touch V2 DOC.60352-11/20
48
The following buttons are at the bottom of the screen:
APPLY
The apply button is used to save the encoder values in
their working positions (copy the current to saved
value).
It is not necessary to press the apply button after
making any tolerance or control/configuration changes.
RESET
Used to reset the default values for the saved position
and for the tolerances.
DELETE
Used to remove a position (requires confirmation).
SELECT IMAGE
For a dynamic display of the screwdriving step, with an
image of your choice (see paragraph 4.4.4.).
RIGHT ARROW
To create a new position or navigate to the next
position.
LEFT ARROW
To navigate to previous positions.
A fastening step can be programmed manually or automatically.
Pick up
positions 1 & 2
Allows the tool to start in a specific position or area
(outside position OK zone) in order to pick up a screw.
Fastening OK signals and Motor run signals are not
effective on pick-up position.
Driver 1 / 2
(RJ45 port)
Only used for DOGA tools (GX, GY, DO, GA) connected
through RJ45 port. This selection allows enabling and
disabling tools for each individual position
