User manual DPC Touch V2 DOC.60352-11/20
Pick-to-light indicator 1 is turned off once picking is
performed.
Text or Image message is shown on the screen to
indicate first fastening operations to be performed.
First fastening operations are performed, screws are
counted and tool position is assured.
Text or image message is shown on the screen to
indicate parts to be picked.
One output signal (continuous) is sent to turn on
pick-to-light indicator 2.
One input signal (active high) is expected for picking
verification by sensor 2.
Pick-to-light indicator 2 is turned off once picking is
performed.
Text or Image message is shown on the screen to
indicate second fastening operations to be performed.
Second fastening operations are performed, screws are
counted and tool position is assured.
Two output signals are disabled to open the clamping
device and to turn off assembly status light.
Delay before the job restarting.
