DOGA DPC TOUCH V2 - Page 95

User manual DPC Touch V2 DOC.60352-11/20
95
Adr.
Status
Function code
3311
Action result
Job select - Job no
Step select - Fastening (Step total
screw), Input (Input value), Output (0),
Delay (Delay time), Message (0)
Fasten - 0: NG 1: OK
0x04
3312
Error code
0x20: Not work,
0x21: Step Ng,
0x22: Job Ng,
0x23: Workpiece Ng,
0x24: Alarm,
0x25: Fasten time Ng,
0x26: Fasten no torque-up Ng,
0x27: Fasten skip Ng
0x04
3313
Job total screw
0x04
3314
Job remain screw
0x04
3315
Step total screw
0x04
3316
Step remain screw
0x04
3317
Fastening position ch1
0x04
3318
Fastening position ch2
0x04
3319
Fastening position ch3
0x04
3320
Fastening position ch4
0x04
3321
Barcode data 32
character
0x04
3353
0x04
