- Rotating Atomizer with External Charging
Version:: 07 • As of:: 01/2020
Volumetric measurement of the detergent
The required amount of detergent can also be determined by the
principle of volumetric measurement. The quantity of detergent is
determined by the pressure. The pressure depends on the system
configuration. The table below shows how much rinsing agent is
necessary for optimal cleaning results.
Valve operation Volumetric
measurement
via
Ignitable paint Non-flammable
Paint
Short flush of bell
disk total
Flush borings 500 ± 50 ml/min 700 ± 50 ml/min
Ignitable paint may not be used with external charging.
If the required amount of rinsing agent is not obtained or exceeded,
the quantity must be regulated via a pressure change.
Final work
After the volumetric measurement of the atomizer, bring it back to a
working condition.
• Remove Adapter.
• Clean nozzle and the end of the shaft.
A T T E N T I O N
Risk of damage to property and production disruption
Dirt on the thread of the shaft prevents proper seating of the bell disk
and leads to unbalance.
Upon conclusion of volumetric measurement, check cleanliness.
• Screw on bell disk (see "bell disk assembly").
Pos: 40 /INP/ Bell2/06_05 S pülen @ 57\mod _150641 9664445_20. docx @ 621653 @ 2 33 @ 1
