Dr.coffee M12 - M12 Power Board Circuit

Rev 0.1
Dr.coffee Service Manual 13
4.2 M12 Power Board Circuit
Steam Thermobloak
FireWire L
Coffee Thermobloak
FireWire L
Power Firewire L
Power neutral N
Coffee Pump
DC 24V output line
Steam Pump
1# Transformer AC 20v Line
2# Transformer AC 20v Line
DC 24VOutput line
Main control board communication line
1# Transformer AC 220V Line
transformer
AC 220v
Line
2# Transformer AC 220V Line
transformer
AC 220v
Line
Grinding motor
power
cordtransformer
AC 220v
Line
Steam Thermo block neutral N
Coffee Thermo block neutral N
