Dr.coffee Service Manual 60
10.2.3 Disassemble Pressure Releasing Valve
Step1：First (as shown in Figure 1), hold the gear lever bracket and remove the gear lever set in the direction of the
arrow.
Step2：Press with a flat-blade screwdriver (as shown in Figure 1, 2), eight red circles indicate the position of the
buckle, and release the buckle to remove the two side panels (Figure 3)
Step3：Grasp the pressure relief valve block with your hand and pull out the pressure relief valve group in the direction
indicated by the arrow (Figure 1). Disassemble the group.
★ Attention：
1、Please cool down the machine before disassembling to prevent burns！
