Dr.coffee M12 - Electrical Component Disassembly

Rev 0.1
Dr.coffee Service Manual 61
10.2.4 Disassemble Drive Motor Group
Step 1：Remove（Pic.1）plug here；
Step2：Remove the 2 screws with T20（pic.2），grab drive motor group push down and take out.
★ Attention：
1、 Please cool down the machine before disassembling to prevent burns！
1
4
2
3
