Dr.coffee M12 - Technical Data; Capacity and Specifications

Rev 0.1
Dr.coffee Service Manual 14
5 Technical Data
5.1.1 Capacity
Hourly Output Based On DIN18873-2:
Model
M12
Advised daily output
100 cups
Hourly output
Espresso（Medium 50ml）
85 cups
Americano（Medium 240ml）
75 cups
Cappuccino（Medium 200ml）
65 cups
Hourly hot water output
30L
Water tank capacity
Small 2L/Large 8L
Beans hopper capacity
1000g
Grounds container capacity
70pcs(10g/pc)
Drip Tray
About 1.5L
5.1.2 Technical sheet
Model
M12
M12 Big
M12 Plus
M12 Big Plus
Rated Voltage
220v-240v AC～50/60Hz
Rated Power
2900W
Plumbing Type
G3/4’ to G3/8’ 150cm flexible metal tube
Water Pressure Range
No pressure
Max. 0.6Mpa
Coffee machine Dimension w*d*h
With small water tank 300*500*580mm/ With large water tank
410*500*580mm
Weight
With small water tank 19Kg/ With large water tank 20.5Kg
