3. WP8010 INSTALLATION
D-306233 CUSDOC PM-10/30 V18 DSC TRIPLE EN INST 51
Define whether the control panel will stay continuously connected "enabled", via GPRS
communication, or disconnect "disabled" (default), after each report session.
Note: For UL installations, set to “enabled”.
Some GSM Service providers tend to disconnect the GSM connection if the user has not
initiated any outgoing telephone calls during the last 28 days. To prevent from
disconnecting the GSM connection, you can configure the system to generate a "keep
alive" GSM call every 28 days sending a test message either to the first SMS number
(if exists) or alternatively first private telephone number.
Options: Disable (default) or Every 28 days.
Select the IP protocol used to transfer data over the internet/GPRS.
Options: TCP (default); or UDP.
5.6.4 Configuring Events Reporting to Monitoring Stations
The WP8010/WP8030 control panel is designed to report alarm, alerts, troubles and other events and messages to two
Monitoring Stations C.S.1 and C.S.2 via PSTN telephone line, Cellular i.e. GSM voice (analog), GPRS (IP) & SMS or
Broadband IP communications channels. In this section you configure and define all parameters and features required
for the reporting of the event messages to Monitoring Stations such as:
The events reported to each of the two Monitoring Stations C.S.1 and C.S.2 and corresponding backups.
The communication means (channel) used for the reporting and the backup means (channel) in case of failure.
The customer's (subscriber) account number(s) to be reported to each monitoring station.
The telephone numbers, IP addresses and SMS numbers and reporting formats of the corresponding alarm receivers
at the two Monitoring Stations C.S.1 and C.S.2 and the number of reporting retry attempts in case of failure to report.
The communication Auto Tests and communication Fail reports.
The reporting of certain system function events such as "Confirmed Alarm", "Recent Close", Zone Restore" and
"System Not-Used".
Notes: The notification of events to other 3rd party applications (SMS/IP/personal phones) is a supplementary
feature that has not been investigated by UL and is not used in UL listed installations.
04:COMMUNICATION
3:C.S.REPORTING
MENU you wish
Enter "3:C.S.REPORTING", select the menu you wish to configure (see guidance above and in section 5.6.1), then
refer to the table below which provides you with detailed explanations and configuration instructions for each option.
Configuration Instructions
Define which events (i.e. Alarms (alrm); Open/close (o/c); Alerts (alrt); All events (all);
Maintenance and Troubles) will be reported to the Monitoring Stations.
The minus (-) symbol means "less/except" e.g. all(-alrt) means all events except alerts.
The asterisk () is a separator between events reported to Monitoring Station 1 (C.S.1) and
events reported to Monitoring Station 2 (C.S.2). For detailed and more complete explanation
see the "Event Reporting Chart" at the end of this section.
all-o/c backup (default)
Note: Alarm events (alrm) have highest priority and Alert events (alrt) have lowest priority.
02:1st RPRT CHAN
03:2nd RPRT CHAN
04:3rd RPRT CHAN
If the system is equipped also with Cellular communicators, you must define which of the
communicating channels (i.e. Cellular, Broadband or PSTN) the system will use as the main
channel (i.e. 1
st
priority) for reporting event messages to Monitoring Stations, and if the main
channel fails, which channels will be used for the 2
nd
and 3
rd
reporting priorities.
Enter the "1
st
RPRT CHAN"; option and define which of the communication channels the
system will use as the main reporting channel. To define also backup reporting channels, enter
the "2nd RPRT CHAN" and "3rd RPRT CHAN" options and define them as well.
Options: disable (default); cellular; broadband and PSTN.
If the selected main reporting channel fails, the system will use the other
communication channel to report event messages to Monitoring Stations. If none
is selected, the reporting to monitoring stations will be disabled.
