3. WP8010 INSTALLATION
D-306233 CUSDOC PM-10/30 V18 DSC TRIPLE EN INST 55
Event Reporting Chart
To simplify the configuration of reporting system events to Monitoring Stations, the event messages are divided into 4
Event Groups as described in the following table below: Due to lack of space in the display, the following abbreviations
are used alrm, alrt, o/c” and all (i.e. all events).
Fire, CO, Burglary, Panic, Tamper
Arming AWAY, Arming HOME, Disarming
No-activity, Emergency, Latchkey
All other Trouble events not indicated above, e.g. Low battery, AC failure, Missing, Jamming,
Communication Fail etc.
Note: "Alarms" group has the highest priority and "Alerts" group has the lowest priority.
The WP8010/WP8030 allows you also to select which event groups will be reported to each of the two Monitoring
Stations. The table below describes the available reporting options. The minus (-) symbol means "but/less/except" e.g.
all(-alrt) means all events except alerts. The asterisk () is a separator between event messages reported to
Monitoring Station 1 (C.S.1) and event messages reported to Monitoring Station 2 (C.S.2).
Available Reporting Options
Events Reported to C.S. 1
Events reported to C.S. 2
All, only if C.S.1 does not respond
All but open/close, only if C.S. 1 does not respond
Note: “all” means that all 5 Groups are reported including Trouble messages - sensor / system low battery, sensor
inactivity, power failure, jamming, communication failure etc.
5.6.5 Configuring Events Reporting to Private Users
The WP8010/WP8030 system can be programmed to send various event notifications such as alarm, arming or trouble
events, to 4 Private telephone subscribers using audible signals and if a GSM option is installed, the system can send
the messages also to 4 emails, MMS and SMS telephone numbers via the server. These reports can be programmed
either instead of or in addition to the reports transmitted to the monitoring company. In this section you configure:
The specific events you wish the system to report.
The 1
st
, 2
nd
, 3
rd
, and 4
th
Private telephone and SMS numbers of the private subscribers.
Event notification messages to be sent to 1
st
, 2
nd
, 3
rd
, and 4
th
private emails and private MMS and SMS telephone
numbers via the server.
The number of redial attempts, two-way voice communication
and your preferred acknowledge method i.e.
whether a single acknowledge signal will stop the reporting process or an acknowledge signal from each telephone
will be required before the reported event is considered reported.
To select and configure an option follow the instructions below. Additional guidance is provided in section 5.6.1.
04:COMMUNICATION
4:PRIVATE REPORT
MENU you wish
The "4:PRIVATE REPORT" menus and sub-menus configuration is shown in the table in section 5.6.1. For a detailed
description of the menus options, refer to the User's Guide Chapter 6, section B.12.
5.6.6 Configuring Motion Cameras for Visual Alarm Verification
If equipped with a GSM/GPRS module, the WP8010/WP8030 can communicate to Monitoring Stations (equipped with
DSC PowerManage server) via the GPRS network, also with image clips captured by Motion Cameras (models
PG9934, Next-PG9904 and PG9944). The Monitoring Station can use the video clips for verification of Burglary alarms
detected by the Motion Cameras. The system can be configured to capture image clips also upon occurrence of Non-
Burglary alarms (i.e. Fire, Duress, Emergency and Panic). The server can then forward the images to the management
computer of the monitoring station or to 4 remote computers via e-mail and/or 4 mobile phones by MMS images.
In addition, the monitoring station can log into the PowerManage server and request the system to provide image clips
Refers to WP8030 with voice option only
