DSC WP8030

3. WP8010 INSTALLATION
82 D-306233 CUSDOC PM-10/30 V18 DSC TRIPLE EN INST
WP8010
WP8030
Real Time Clock
(RTC)
The control panel keeps and displays time and
date. This feature is also used for the log file by
providing the date and time of each event
The control panel keeps and displays time and
date. This feature is also used for the log file by
providing the date and time of each event
Battery Test
Once every 10 seconds
Once every 10 seconds
A2. Wireless
WP8010
WP8030
RF Network
PowerG – 2-way synchronized Frequency
Hopping (TDMA / FHSS)
PowerG – 2-way synchronized Frequency
Hopping (TDMA / FHSS)
Frequency bands
(MHz)
433 – 434
868 - 869
912 – 919*
433 – 434
868 - 869
912 – 919*
Hopping
frequencies
8
4
50
8
4
50
Region
Worldwide
Europe
North
America and
selected
countries
Worldwide
Europe
North
America and
selected
countries
Encryption
AES-128
Note: AES-128 bit encryption for
communication between control unit and
initiating devices is not suitable as a means of
Encrypted Line Security in UL Listed product.
AES-128
Note: AES-128 bit encryption for
communication between control unit and
initiating devices is not suitable as a means of
Encrypted Line Security in UL Listed product.
* For UL Listed product, enable this frequency band.
A3. Electrical
WP8010
WP8030
External AC/AC
adaptor
Europe: 230VAC 50Hz input, 9VAC 700mA
output.
USA: 120VAC 60Hz input, 9VAC 1000mA
output.
NA
External AC/DC
adaptor
NA
External (wall-mounted) switching power
supply 100VAC to 240VAC, 50/60 Hz, 0.5A /
12.5 VDC, 1.2A
Internal AC/DC
Internal switching power supply:
Input: 100-240VAC, 0.12 A Max.
Output: 7.5VDC, 1.2A Max.
Internal switching power supply:
Input: 100-240VAC, 0.75A
Output: 12.5 VDC, 1.6A.
Current Drain
Approx. 240 mA standby at the beginning
(power ON) and then goes down to 90 mA
standby, 1200 mA peak at full load.
The Plink module draws 200mA in quiescent
condition and 350mA during communication.
The cellular modem draws 25mA in quiescent
condition and 300mA during communication.
Note: When there is an AC fail the Plink
module is disconnected.
Approx. 260 mA standby, at the beginning
(power ON) and then goes down to 60 mA,
1400 mA max. current drain during alarm.
Low Battery
Threshold
4.8 V
7.2 V (6-cell battery pack)
9.6 V (8-cell battery pack)
Backup Battery
Pack
4.8V 1300 mAh, rechargeable NiMH battery
pack, p/n GP130AAM4YMX, manufactured by
GP or p/n LTT-1300AA4Y, manufactured by
LTT.
4.8V 1800 mAh, rechargeable NiMH battery
pack, p/n GP180AAH4YMX, manufactured by
GP or p/n LTT-1800AA4Y, manufactured by
LTT.
4.8V 2200 mAh, rechargeable NiMH battery
pack, p/n GP220AAH4YMX, manufactured by
GP or p/n LTT-2300AA4Y, manufactured by
LTT. For UL Listed product, use these
batteries only.
Backup Battery Options:
Backup period
Maximum external devices current (1)
1300 mAh
6 Battery
Pack (2)
1800 mAh
8-Battery
Pack (3)
2200 mAh
8-Battery
Pack (4)
4h
180 mA
300mA
380mA
8h
70 mA
125 mA
160 mA
12h
35 mA
70 mA
95 mA
24h
max backup
w/o load 22
hours
12 mA
25 mA
32h
no backup
0mA
10 mA
39h
no backup
no backup
0 mA
