DSC WP8030 Installer's Guide

3. WP8010 INSTALLATION
D-306233 CUSDOC PM-10/30 V18 DSC TRIPLE EN INST 81
APPENDIX A. Specifications
A1. Functional
WP8010
WP8030
Zones Number
30 wireless zones (including 1 hard-wired
input).
Up to 64 wireless zones, (including 2 hard-
wired inputs).
Hard-wired Zone
Requirements
2.2 kE.O.L. resistance (max. resistance of
wires 220 
2.2 kE.O.L. resistance (max. resistance of
wires 220 
Maximum Loop
Current
1.5 mA
1.5 mA
Maximum Loop
Voltage
3.3 V
3.3 V
Loop Shorted
0.00 – 1.47 V (0.00 – 1.76 KΩ)
0.00 – 1.47 V (0.00 – 1.76KΩ)
Loop Normal
1.47 – 1.80 V (1.76-2.64 KΩ)
1.47 – 1.80 V (1.76 – 2.64 KΩ)
Loop Tampered
1.80 – 2.03 V (2.64-3.52 KΩ)
1.80 – 2.03 V (2.64 – 3.52 KΩ)
Loop Alarm
2.03 – 2.33 V (3.52-5.26 KΩ)
2.03 – 2.33 V (3.52 – 5.26 KΩ)
Loop Open
2.33 – 3.30 V (5.26 - ∞ Ω)
2.33 – 3.30 V (5.26 – ∞ Ω)
Installer and User
Codes
 1 master installer (9999 by default)*
 1 installer (8888 by default)*
 1 master user, no. 1 (1111 by default)
 Users nos. 2 - 8
* Codes must not be identical
 1 master installer (9999 by default)*
 1 installer (8888 by default)*
 1 master user, no. 1 (1111 by default)
 Users nos. 2 - 48
* Codes must not be identical
Control Facilities
- Integral keypad, wireless keyfobs and
keypads
- SMS commands via optional GSM/GPRS
module.
Remote control by telephone.
Note: For SIA CP-01 compliance, when using
PG9939 an external siren must also be used.
CP-01 features not to be enabled in UL Listed
product.
- Integral keypad, wireless keyfobs and
keypads
- SMS commands via optional GSM/GPRS
module.
- Remote control by telephone.
Note: For SIA CP-01 compliance, when using
PG9939 an external siren must also be used.
CP-01 features not to be enabled in UL Listed
product.
Display
Single line, backlit 16-large character LCD.
Single line, backlit 16-large character LCD.
Arming Modes
AWAY, HOME, AWAY-INSTANT, HOME-
INSTANT, LATCHKEY, FORCED, BYPASS.
Note: AWAY-INSTANT and HOME-INSTANT
are not permissible for CP-01 installations.
AWAY, HOME, AWAY-INSTANT, HOME-
INSTANT, LATCHKEY, FORCED, BYPASS.
Note: AWAY-INSTANT and HOME-INSTANT
are not permissible for CP-01 installations.
Alarm Types
Silent, personal panic/emergency, burglary,
gas (CO), and fire .
Silent, personal panic/emergency, burglary,
gas (CO), and fire.
Siren Signals
Continuous (intrusion / 24 hours / panic); triple
pulse – short pause - triple pulse... (fire);
four pulses – long pause – four pulses... (gas);
long pulse – long pause – long pulse... (flood).
Continuous (intrusion / 24 hours / panic); triple
pulse – short pause - triple pulse... (fire);
four pulses – long pause – four pulses... (gas);
long pulse – long pause – long pulse... (flood).
Siren (bell) Timeout
Programmable (4 min. by default)
Programmable (4 min. by default)
Internal Sounder
Output
At least 85 dBA at 10 ft. (3 m)
At least 85 dBA at 10 ft. (3 m)
Supervision
Programmable time frame for inactivity alert
Programmable time frame for inactivity alert
Special Functions
- Chime zones
- Diagnostic test and event log.
- Local and Remote Programming over
Telephone, GSM /GPRS connections.
- Calling for help by using an emergency
transmitter.
- Tracking inactivity of elderly, physically
handicapped and infirm people.
Note: Tracking inactivity of elderly not to be
enabled in UL Listed product.
- Chime zones
- Diagnostic test and event log.
- Local and Remote Programming over
Telephone, GSM /GPRS connections.
- Calling for help by using an emergency
transmitter.
- Tracking inactivity of elderly, physically
handicapped and infirm people.
- Message center (recording and playback)
- Two-way voice communication
Note: Tracking inactivity of elderly not to be
enabled in UL Listed product.
Data Retrieval
Alarm memory, trouble, event log
Alarm memory, trouble, event log

DSC WP8030 Specifications

General

Brand	DSC
Model	WP8030
Category	Control Panel
Language	English
