GBK51948 RHINO2
Installation Manual Issue 5
6.5.5.12 Motor Testing
Parameter Possible Values Default HHP Lite Std Adv
Motor Testing
None
Open (Pre-Drive Only)
Short
All (Open Pre-Drive Only)
Open (Pre-Drive and Drive)
All (Open Pre-Drive and Drive)
Short
✓
This parameter is set to determine which tests are performed on the motor (open circuit /
short circuit) and when they are performed (before driving / during driving).
All (Open Pre-Drive Only)
-
Test the motor for both open and short circuits.
The motor is tested for open circuits before starting to drive.
The motor is tested for short circuits before driving and continuously
while driving.
All (Open Pre-Drive and
Drive)
-
Test the motor for both open and short circuits.
Open circuit testing is performed before and during driving.
The motor is tested for short circuits before driving and continuously
while driving.
Open (Pre-Drive and
Drive)
-
Test the motor for open circuits.
Open circuit testing is performed before and during driving.
Use this setting if low impedance motors are being detected as a short
circuit.
Short
-
Test the motor for short circuits.
The motor is tested for short circuits before driving and continuously
while driving.
Open (Pre-Drive Only)
-
Test the motor for open circuits.
Open circuit testing is performed before driving only.
None
-
Disable all motor testing.
Warning
1. For safety reasons, do not set this parameter to 'None' unless for testing in a controlled environment.
2. The safest option is "All (Open Pre-Drive and Drive)".
3. Only set this parameter to 'Open (Pre-Drive and Drive)' or 'Short' if the motors that are used are failing
the test and they have been fully tested to make sure that they are healthy.
4. Only set this parameter to 'Open (Pre-Drive Only)' or 'All (Open Pre-Drive Only)' if the open circuit test
while driving gives false faults or undesirable behaviour (such as increased motor noise).
6.5.5.13 Maximum Motor Voltage
Parameter Possible Values Default HHP Lite Std Adv
Maximum Motor Voltage 0 - 64 V 26.2 V
✓
Maximum Motor Voltage sets the maximum voltage that the RHINO2 will apply to the motor.
Note
If local regulations require that the scooter speed is limited to a specific value, use this parameter to set a
speed limit for a particular scooter type (for specific motors and a specific wheel diameter).
Page 102 - Programming
