6.5.10.3 Pin 10 Function
Parameter Possible Values Default HHP Lite Std Adv
Pin 10 Function
None
Status High
Status Low
Fault High
Fault Low
5V Gauge
12V Gauge
Other
Status High
✓ ✓
Sets the function of Pin 10 on the tiller connector. Pin 10 is capable of sinking 50 mA at 24
V and sourcing 10 mA at 12 V.
None — The output is not used.
Status High — The output pin drives a 12 V Status LED (10 mA max). The Status LED is on
when the power is on. When a fault condition exists, the Status LED shows the related flash
code. Connect the LED between pin 10 and B-. Install a resistor that limits the current to
10 mA at 12 V. See also 5.9.10 Status Indicator Output.
Status Low — The output pin drives a 24 V Status LED or lamp (50 mA max). The Status
LED is on when the power is on. When a fault condition exists, the Status LED shows the
related flash code. Connect the LED between B+ and pin 10. Install a resistor that limits the
current to 50 mA at 24 V. See also 5.9.10 Status Indicator Output.
Fault High — The output pin drives a 12 V Fault LED (10 mA max). The Fault LED is off
when the power is on and no fault condition exists. When a fault condition exists, the Fault
LED shows the related flash code. If the system is in Sleep Mode when a fault condition
exists, the Fault LED does not show the related flash code. Connect the LED between pin
10 and B-. Install a resistor that limits the current to 10 mA at 12 V. See also 5.9.10 Status
Indicator Output.
Fault Low — The output pin drives a 24 V Fault LED or lamp (50 mA max). The Fault LED is
off when the power is on and no fault condition exists. When a fault condition exists, the
Fault LED shows the related flash code. If the system is in Sleep Mode when a fault
condition exists, the Fault LED does not show the related flash code. Connect the LED
between B+ and pin 10. Install a resistor that limits the current to 50 mA at 24 V. See also
5.9.10 Status Indicator Output.
5V Gauge — The pin will show the state of the battery on an analogue 5 V voltmeter battery
gauge. Connect the battery gauge between pin 10 and B-. See also 5.9.12 Battery Gauge
Output.
12V Gauge — The pin will show the state of the battery on an analogue 12 V voltmeter
battery gauge. Connect the battery gauge between pin 10 and B-. See also 5.9.12 Battery
Gauge Output.
Page 120 - Programming
