Other — Drives a digital multi-LED battery gauge display. Connect the LED battery gauge
between B+ and B-. Connect pin 10 to the "Data In" input of the LED battery gauge.
If a Battery Charger inhibit is activated, the gauge shows a charging sequence.
If a flash code condition exists, the flash code number is indicated by the number of flashes
(same as for a single status indicator), regardless of the number of bars lit. The number of
bars lit continues to indicate the battery gauge level during flash code indication.
To indicate to the user when the scooter is in Sleep Mode, one or two LED bars
‡1
will flash
once every 5 seconds.
Note
‡1 — The number depends on the gauge fitted, and the RHINO2 firmware version.
6.5.10.4 Key Switch Status LED
Parameter Possible Values Default HHP Lite Std Adv
Key Switch Status LED No / Yes Yes
✓
To reduce current drain, set this parameter to 'No' if a status LED is not wired in series with
the key switch.
