ID Name Data values Description
LSBcorresponds to 250 mV.
0x0B Pin TH14 level 0–255
Integer part of voltage on pin TH14. Note that 1
LSBcorresponds to 250 mV.
0x0C
Month of
manufacture
1–12
Indicates the month the RHINO2 controller module
was manufactured. 1 — January, 2 — February, etc.
0x0D
Year of
manufacture
0–99
Indicates the year the RHINO2 controller module was
manufactured
0x0E
Serial number —
byte 1
0–255
Controller serial number — first byte of four-byte value
— most significant byte
0x0F
Serial number —
byte 2
0–255
Controller serial number — second byte of four-byte
value
0x10
Serial number —
byte 3
0–255
Controller serial number — third byte of four-byte
value
0x11
Serial number —
byte 4
0–255
Controller serial number — fourth byte of four-byte
value — least significant byte
0x12
Controller current
rating
90, 120, 160
or 180
Current rating of controller
0x13
Time controller
powered up — byte
1
0–255
Time in minutes the controller has been powered up —
first byte of 3-byte value — most significant byte
0x14
Time controller
powered up — byte
2
0–255
Time in minutes the controller has been powered up —
second byte of 3-byte value
0x15
Time controller
powered up — byte
3
0–255
Time in minutes the controller has been powered up —
third byte of 3-byte value — least significant byte
0x16
Controller power
up count — byte 1
0–255
Number of times controller has been powered up —
first byte of 3-byte value — most significant byte
0x17
Controller power
up count — byte 2
0–255
Number of times controller has been powered up —
second byte of 3-byte value
0x18
Controller power
up count — byte 3
0–255
Number of times controller has been powered up —
third byte of 3-byte value — least significant byte
0x19
Controller driving
time — byte 1
0–255
Time in minutes the controller has been driving — first
byte of 3-byte value — most significant byte
0x1A
Controller driving
time — byte 2
0–255
Time in minutes the controller has been driving —
second byte of 3-byte value
0x1B
Controller driving
time — byte 3
0–255
Time in minutes the controller has been driving — third
byte of 3-byte value — least significant byte
0x1C
Controller drive
count — byte 1
0–255
Number of times controller has been driven — first
byte of 3-byte value — most significant byte
0x1D
Controller drive
count — byte 2
0–255
Number of times controller has been driven — second
byte of 3-byte value
0x1E
Controller drive
count — byte 3
0–255
Number of times controller has been driven — third
byte of 3-byte value — least significant byte
Page 138 - Diagnostics
