ID Name Data values Description
0x1F
Battery deep
discharge count —
byte 1
0–255
Number of times of battery deep discharge — first byte
of 2-byte value — most significant byte
0x20
Battery deep
discharge count —
byte 2
0–255
Number of times of battery deep discharge — second
byte of 2-byte value — least significant byte
0x21
Battery overcharge
count — byte 1
0–255
Number of times of battery overcharge — first byte of
2-byte value — most significant byte
0x22
Battery overcharge
count — byte 2
0–255
Number of times of battery overcharge — second byte
of 2-byte value — least significant byte
0x23
Internal condition
Code — byte 1
0–255
Internal condition Code — first byte of 2-byte value —
most significant byte
0x24
Internal condition
Code — byte 2
0–255
Internal condition Code — second byte of 2-byte value
— least significant byte
0x25 Active flash code
See "Flash
Code Display"
on page 124
Number of flashes for the active flash code (flash code
will depend on the programmed flash code type)
0x26
RHINO2 software
version
0–255
Version part of the software version.revision value. For
example: 0x01 for the "1" in V1.26
0x27
RHINO2 software
revision
0–255
Revision part of the software version.revision value.
For example: 0x1A (26 dec) for the "26" in V1.26
0x28 Battery voltage
1
0–255
Battery voltage between 0 and 31.875 V. Note that
1 LSB = 125 mV.
0x29
Ambient
temperature
1
-128 to +127
Ambient temperature with nominal range between -80
to +120, which represents temperatures between
-40 °C and +60 °C. Note that 1 LSB = 0.5 °C. Values -
128 and +127 indicate an open circuit or short circuit
fault.
0x2A Motor current
1
-127 to +127
Motor current units representing a current range from -
254 A to + 254 A. Note that 1 LSB = 2 A.
0xFF
End of data
transfer
0–255
8-bit checksum of all preceding bytes in this transfer.
Note 1: Battery voltage, ambient temperature and motor current data are only available in the Full Data
transmission when the 1 Hz Data transmission is disabled.
GBK51948 RHINO2
Installation Manual Issue 5
Diagnostics - Page 139
