Dynapac CA3500DCP User Manual

Maintenance - Maintenance schedule
4812165301.pdf2022-09-02
Maintenance - Maintenance schedule
Service and maintenance points
29, 30
2, 3
4
5
6,7,10
7
8
9
11
12
13
14
14
16
17,18
20
21
22,23
25
26
1
11
15
31,32
19
27
33,34
Fig. Service and maintenance points
1. Diesel fuel, filling 14. Scrapers 27. Seat bearing *1. Diesel fuel, filling 14. Scrapers 27. Seat bearing *
2. Oil level, diesel engine 15. Battery 28. Steering chain *2. Oil level, diesel engine 15. Battery 28. Steering chain *
3. Fuel filter, fuel pre-filter 16. Rubber elements and fastening
screws
29 DEF tank, filter3. Fuel filter, fuel pre-filter 16. Rubber elements and fastening
screws
29 DEF tank, filter
4. Air filter 17. Steering hitch 30 DEF pump, filter4. Air filter 17. Steering hitch 30 DEF pump, filter
5. Engine cover, hinges 18. Steering cylinders, x2 31. Water cooler5. Engine cover, hinges 18. Steering cylinders, x2 31. Water cooler
6. Hydraulic reservoir, sight glass 19. Drive belts 32. Hydraulic fluid cooler6. Hydraulic reservoir, sight glass 19. Drive belts 32. Hydraulic fluid cooler
7. Bleeding filter 20. Wheel nuts 33. Fresh air filter *7. Bleeding filter 20. Wheel nuts 33. Fresh air filter *
8. Hydraulic fluid filter, x1 21. Tires, pressure 34. Air conditioning *8. Hydraulic fluid filter, x1 21. Tires, pressure 34. Air conditioning *
9. Drainage, hydraulic fluid
reservoir
22. Rear axle, differential9. Drainage, hydraulic fluid
reservoir
22. Rear axle, differential
10. Hydraulic fluid, filling 23. Rear axle, planetary gears, 2 pcs.10. Hydraulic fluid, filling 23. Rear axle, planetary gears, 2 pcs.
11. Fuse box(es), main fuses11. Fuse box(es), main fuses
12. Drum cartridge, filling, 2 fillers 25. Oil filter, diesel engine12. Drum cartridge, filling, 2 fillers 25. Oil filter, diesel engine
13. Drum gearbox 26. Draining, fuel tank *13. Drum gearbox 26. Draining, fuel tank *
* Optional equipment* Optional equipment
General
Periodic maintenance should be carried out after the
number of hours specified. Use the daily, weekly etc.
periods where number of hours cannot be used.
105
