Maintenance - Maintenance schedule
4812165301.pdf2022-09-02
Every 1000 hours of operation
Refer to the contents to find the page number of the
sections referred to !
Pos. in fig Action CommentPos. in fig Action Comment
8 Change the hydraulic fluid filter8 Change the hydraulic fluid filter
12 Check the oil level in drum cartridges12 Check the oil level in drum cartridges
12 Cleaning the ventilation screws in the drum
cartridges
12 Cleaning the ventilation screws in the drum
cartridges
12 Inspect the oil level glass in drum cartridges Replace as required12 Inspect the oil level glass in drum cartridges Replace as required
4 Inspect the filter element in the air cleaner Replace as required4 Inspect the filter element in the air cleaner Replace as required
22 Change oil in rear axle differential22 Change oil in rear axle differential
23 Change oil in the rear axle planetary gearing23 Change oil in the rear axle planetary gearing
13 Change the oil in drum gearbox Only for machines with
drum gearbox.
13 Change the oil in drum gearbox Only for machines with
drum gearbox.
32,31 Clean the coolers32,31 Clean the coolers
3 Replace the fuel filter Refer to the engine manual3 Replace the fuel filter Refer to the engine manual
3 Replace the fuel pre-filter Refer to the engine manual3 Replace the fuel pre-filter Refer to the engine manual
2,25 Change the engine oil and oil filter. *) Refer to the engine
manual*) 500h or once a
year.
2,25 Change the engine oil and oil filter. *) Refer to the engine
manual*) 500h or once a
year.
7 Check bleeder filter on hydraulic reservoir7 Check bleeder filter on hydraulic reservoir
9 Drain the condensate from hydraulic reservoir9 Drain the condensate from hydraulic reservoir
26 Drain condensate from fuel tank Optional26 Drain condensate from fuel tank Optional
33 Replace the fresh air filter in the cab Optional33 Replace the fresh air filter in the cab Optional
19 Check belt tension in the drive belt system Refer to the engine manual19 Check belt tension in the drive belt system Refer to the engine manual
17 Steering hitch - Tightening17 Steering hitch - Tightening
