Operation
4812165301.pdf 2022-09-02
Close the engine hood.
When operating position is activated, offset adjustment
can then take place, after which connection to the
roller is possible.
Connecting compaction plates
1
The operator and instructing person must be able to
maintain good contact and a safe distance from the
machine and compaction plates.
2
Make sure that the two set screws at the bottom of the
machine’s lifting arms are screwed in all the way. If
necessary, loosen the lock nuts and screw in the
screws. Release the lock bar.
To reverse the roller with the lifting device in the low
position, “Service mode” must be selected in the
“Machine settings” menu in the roller’s operator
display.
Reverse the machine slowly into position with the
lifting arms at a suitable height.
80
