Dynapac CA3500DCP User Manual

Technical specifications
4812165301.pdf 2022-09-02
Dimensions, side view
Dimensions mm inDimensions mm in
A Wheelbase, drum and wheel 2990 118A Wheelbase, drum and wheel 2990 118
L1 Length, lifting arms in transport position 6350 250L1 Length, lifting arms in transport position 6350 250
L1 Length, lifting arms in work position 6490 255L1 Length, lifting arms in work position 6490 255
L2 Length, with compaction plates (work position) 7360 290L2 Length, with compaction plates (work position) 7360 290
L3 Length, with compaction plates (transport position) 7540 297L3 Length, with compaction plates (transport position) 7540 297
H Height, with cab 2880 113H Height, with cab 2880 113
D Diameter, drum (D) 1520 60D Diameter, drum (D) 1520 60
S Thickness, drum amplitude, Nominal (D) 35 1.4S Thickness, drum amplitude, Nominal (D) 35 1.4
K1 Clearance, tractor frame 450 18K1 Clearance, tractor frame 450 18
K2 Clearance, drum frame 450 18K2 Clearance, drum frame 450 18
16

Dynapac CA3500DCP Specifications

General

Brand	Dynapac
Model	CA3500DCP
Category	Power Roller
Language	English
