Maintenance - 50h
4812165301.pdf 2022-09-02
Pre-fuel filter - Draining
Figure. Pre-fuel filter
1. Drain plug
2. Hand pump
1
2
Unscrew the drain plug (1) at the bottom of the fuel
prefilter.
With the aid of the secondary hand-operated pump,
make certain that all sediment comes out.
Tighten the drain plug as soon as uncontaminated fuel
runs out.
Lifting arms, compaction plates - Lubrication
Fig. Lifting arms, compaction plates
1. Grease nipples, 2 pcs (right/left arm)
1
Grease each nipple (1) with five strokes of a
hand-operated grease gun.
Use grease as specified in the lubricant specification.
124
