Machine description
4812165301.pdf 2022-09-02
No Designation Symbol FunctionNo Designation Symbol Function
25 Parking brake To activate the brakes, press the top of the switch to
change the position of the switch.
To release the brakes, press down the red part at the
same time as the switch and change the position of
the switch.
NOTE:When starting the machine, the parking brake
must be activated.
25 Parking brake To activate the brakes, press the top of the switch to
change the position of the switch.
To release the brakes, press down the red part at the
same time as the switch and change the position of
the switch.
NOTE:When starting the machine, the parking brake
must be activated.
26 Hazard indicators (Optional) Activate the hazard warning light by depressing the
button.
26 Hazard indicators (Optional) Activate the hazard warning light by depressing the
button.
27 Rotating beacon (Optional) Activate the rotating beacon by pressing the switch. (If
the machine has two rotating beacons, both are
activated)
27 Rotating beacon (Optional) Activate the rotating beacon by pressing the switch. (If
the machine has two rotating beacons, both are
activated)
28 Reserve28 Reserve
29 N/A29 N/A
30 Reserve30 Reserve
31 N/A31 N/A
35 Service socket Diagnostic socket.
Gateway is connected here to read the CAN-Open
system.
35 Service socket Diagnostic socket.
Gateway is connected here to read the CAN-Open
system.
Warning indication - membrane panel (Keypad)
"Yellow" - Warning"Yellow" - Warning
- The engine has an alarm in category yellow (Alarm image shown in the display)- The engine has an alarm in category yellow (Alarm image shown in the display)
- Communication with the display is interrupted- Communication with the display is interrupted
- The fuel level is below <10%- The fuel level is below <10%
- Charging absent- Charging absent
"Red" - Warning Flashes red continuously"Red" - Warning Flashes red continuously
- The engine has an alarm in category red (Alarm code shown in the display)- The engine has an alarm in category red (Alarm code shown in the display)
- Communication with the engine is interrupted- Communication with the engine is interrupted
- The engine temperature is too high- The engine temperature is too high
- Low oil pressure in the engine- Low oil pressure in the engine
- The air filter is clogged- The air filter is clogged
- The hydraulic fluid temperature is too high- The hydraulic fluid temperature is too high
- The hydraulic fluid filter is clogged- The hydraulic fluid filter is clogged
38
