Eaton EASY-E4 Series User Manual

4. Operation
4.4 Overview of the menus on the device
Menu options in the status line for work with the circuit diagram and the function
blocks
When you complete your work on the circuit diagram and exit the menu with the ESC
button, you will be able to select from the CANCEL, SEARCH, GO TO, and SAVE options
by scrolling through them with the cursor buttons in the bottommost line.
After editing the function blocks, the CANCEL and SAVE options will be available.
SAVEÓ
Table 39: Programs\Circuit dia-
gram
CANCELÓ
Table 40: Programs\Function
blocks
easyE4 11/18 MN050009 EN www.eaton.com
103

Eaton EASY-E4 Series Specifications

General

Type	Programmable Relay
Digital Inputs	Up to 12
Digital Outputs	Up to 8
Display	LCD
Operating Temperature	-25°C to +55°C
Protection Degree	IP20
Storage Temperature	-40°C to +70°C
Supply Voltage	24 V DC, 100-240 V AC
Analog Inputs	4
Outputs	Relay, transistor
Programming	EASY-SOFT-PRO
Communication	Ethernet, Modbus, CANopen
Expansion	Expandable with additional modules
Relative Humidity	5% to 95% (non-condensing)
Standards	IEC/EN 61131-2, UL 508, CSA C22.2 No. 142
